Mount an SD Card Installed In the Allegro AX

If an SD card has been ejected, you will need to mount it so that it can be used to store files.

Refer to Install and Format an SD Card In the Allegro AX for more information on installing the SD card.

You can mount an SD card through the device's Settings (not through the PCSField Data Collector app).

Before removing the SD card, you must eject it. Refer to Eject an SD Card Installed In the Allegro AX for more information.

Complete the following steps to mount an SD card that has been installed in an Allegro AX:

  1. Tap Settings.

    Settings on Home Window

    Settings on Home Window

  2. Scroll down to Storage and then tap Storage.

    Settings > Storage Window

    Settings > Storage Window

  3. Your SD card should be listed under Portable storage with Ejected under it. Tap the name of the card. A message displays with the option to mount it,

  4. Click Mount.

    When the SD card has been mounted and is ready to use, it will display under Portable storage, along with the amount of storage used and total storage available.

    Portable Storage

    Mounted SD Card
