Mount a Unit on a Flat Surface

An accessory kit (part number 370096-000, Mounting Rail Kit) is available for order to mount certain unit's enclosures against a flat surface. The kit includes 2 plastic mounting brackets (also called flanges) and mounting hardware (4 flat-head screws).

Complete the following steps to install the enclosure on a flat surface using the plastic brackets from the optional accessory kit.

1. Use a 7/16 wrench to loosen the four (4) bolts securing the metal mounting bracket on the back of the enclosure, and then remove the bracket.

2. Place one of the two plastic mounting brackets onto the back of the unit and drive two screws with a slotted screwdriver into the same holes that held the metal bracket in place.



   Enclosure (Back View)

3. Repeat the previous step to attach the other plastic bracket.

4. Place the enclosure against the flat surface where you will mount it.

5. Mark the mounting hole locations for the plastic brackets.

6. Set the enclosure out of the way.

7. Use a hand drill and a metal, masonry, or wood drilling bit to drill four holes into the mounting surface where you marked their locations in a previous step.

8. Place the enclosure back in place where the holes line up and drive in lag bolts or other appropriate fasteners to hold the enclosure in place.
