RM4010 Through RM4020 Accumulator Data Point Settings Fields

The Data Points Settings fields can be accessed through the Data Points link in the Unit Setup pane of the unit's Unit Admin page.

Accumulator Data Point Settings includes the following fields:

RM4014 Accumulator Data Points Settings

Not all data points have Settings.

  • Calculated Use Date — Specifies a base date to calculate differences in readings (for use in reports).

  • Current Accumulator Value — Current reading of the channel. After loading this page, if settings are sent to the unit, the current reading does not reset unless changed by a user.

  • Accumulator Alarm Value — The unit will alarm at this value.

  • Reset on High Alt Channel — If the state of Channel 6 is Open, resets the accumulator to zero.

  • Accumulator Reset Value — The accumulator will reset at this value. The maximum value is 999999. Once the unit hits the reset value, it returns to zero (0).

  • Repeat Alarm Frequency — The number of seconds that the unit will wait between alarms. If the value is set to zero (0), the alarm will not repeat. To have the alarm repeat, the value must be set between 60 and 65535.

  • Reset on Low Alt Channel — If the state of Channel 6 is Closed, resets the accumulator to zero.
